27 July 2025

Animating height in React

A simple guide to animating height on elements with react-use-measure and motion using things like accordions and cards as examples

Studio Arhoj

TLDR;

Below is an example of how to animate height with dynamic content using motion (previously framer-motion) and react-use-measure

"use client";

import { ChevronDown } from "lucide-react";
import { AnimatePresence, motion } from "motion/react";
import Image from "next/image";
import { useState } from "react";
import useMeasure from "react-use-measure";

export function AnimatedCard() {
  const [ref, bounds] = useMeasure();
  const [isOpen, setIsOpen] = useState(false);

  return (
    <motion.div
      className="w-full max-w-sm overflow-hidden rounded-md shadow-md"
      animate={{ height: bounds.height }}
      transition={{ type: "spring", duration: 0.5, bounce: 0 }}
    >
      <div ref={ref} className="flex flex-col gap-4 p-4">
        <Image src="/mug.jpg" alt="mugs" width={600} height={600} />
        <h1
          className="inline-flex cursor-pointer justify-between text-xl underline"
          onClick={() => setIsOpen(!isOpen)}
        >
          Studio Arhoj{" "}
          <ChevronDown
            className={`transition-transform duration-200 ${
              isOpen ? "rotate-180" : ""
            }`}
          />
        </h1>
        <AnimatePresence>
          {isOpen && (
            <motion.p
              initial={{ opacity: 0, filter: "blur(4px)" }}
              animate={{ opacity: 1, filter: "blur(0px)" }}
              exit={{
                opacity: 0,
                filter: "blur(4px)",
                transition: { duration: 0.1 },
              }}
              transition={{ delay: 0.2 }}
            >
              I first sumbled across these mugs in Hens Teeth, Dublin where I
              had to grab a couple of them, and then I had the priveledge of
              visiting the store in Copenhagen and couldn't resist grabbing
              another.
            </motion.p>
          )}
        </AnimatePresence>
      </div>
    </motion.div>
  );
}

There are quite a few moving parts in this, so lets break it down a bit further.

Introduction

Animating height: auto; has always been a challenge with css, luckily there is some modern tooling that makes this trivial, the first big piece is motion which provides a set of motion components which can interpolate movement of elements into smooth transitions, and then we have react-use-measure to measure the boundaries of an element, in our case we care about the height.

Animating height

First we can take a look at what this component looks like without any animation and build from there

Studio Arhoj

"use client";

import { ChevronDown } from "lucide-react";
import Image from "next/image";
import { useState } from "react";

export function Card() {
  const [isOpen, setIsOpen] = useState(false);

  return (
    <div className="flex h-fit w-full max-w-sm flex-col gap-4 rounded-md p-4 shadow-md">
      <Image src="/mug.jpg" alt="mugs" width={600} height={600} />
      <h1
        className="inline-flex cursor-pointer justify-between text-xl underline"
        onClick={() => setIsOpen(!isOpen)}
      >
        Studio Arhoj{" "}
        <ChevronDown
          className={`transition-transform duration-200 ${
            isOpen ? "rotate-180" : ""
          }`}
        />
      </h1>
      {isOpen && (
        <p>
          I first sumbled across these mugs in Hens Teeth, Dublin where I had to
          grab a couple of them, and then I had the priveledge of visiting the
          store in Copenhagen and couldn't resist grabbing another.
        </p>
      )}
    </div>
  );
}

To get this to animate we need to use useMeasure to get the height of the card as the content changes and use a motion.div to animate the change in height, the key thing here is that we can’t use the same element for our measure ref and animation so we’ll have to separate them into a wrapper and inner. We can use the wrapper for animations and the inner for the ref, this means that we’ll have to move our layout options like display and padding onto the inner so that it can calculate the height correctly, we’ll also need to include an overflow of hidden onto the wrapper so that the inner isn’t showing up independently which would hide the animation.

- <div className="flex h-fit w-full max-w-sm flex-col gap-4 rounded-md p-4 shadow-md">
+ <motion.div
    animate={{ height: bounds.height }}
    transition={{ type: "spring", duration: 0.5, bounce: 0 }}
    className="h-fit w-full max-w-sm overflow-hidden rounded-md shadow-md"
  >
+   <div ref={ref} className="flex flex-col gap-4 p-4">

Studio Arhoj

"use client";

import { ChevronDown } from "lucide-react";
import Image from "next/image";
import { useState } from "react";
import useMeasure from "react-use-measure";
import { motion } from "motion/react";

export function Card() {
    const [ref, bounds] = useMeasure();
    const [isOpen, setIsOpen] = useState(false);

    return (
    <motion.div
        animate={{ height: bounds.height }}
        transition={{ type: "spring", duration: 0.5, bounce: 0 }}
        className="h-fit w-full max-w-sm overflow-hidden rounded-md shadow-md"
    >
        <div ref={ref} className="flex flex-col gap-4 p-4">
        <Image src="/mug.jpg" alt="mugs" width={600} height={600} />
        <h1
            className="inline-flex cursor-pointer justify-between text-xl underline"
            onClick={() => setIsOpen(!isOpen)}
        >
            Studio Arhoj{" "}
            <ChevronDown
            className={`transition-transform duration-200 ${
                isOpen ? "rotate-180" : ""
            }`}
            />
        </h1>
        {isOpen && (
            <p>
            I first sumbled across these mugs in Hens Teeth, Dublin where I had
            to grab a couple of them, and then I had the priveledge of visiting
            the store in Copenhagen and couldn't resist grabbing another.
            </p>
        )}
        </div>
    </motion.div>
    );
}

For the majority of cases, it is probably good enough to stop here but occasionally it helps to announce an entrance and exit with animations.

To be able to make use of exit animations we’ll need to reach for AnimatePresence from motion to delay the unmounting of the react component, the typical structure for using this is shown below.

<AnimatePresence>{isOpen && <motion.p>Hello</motion.p>}</AnimatePresence>

This then allows you to include an exit animation to a motion element.

Studio Arhoj

To achieve the full effect of enter and exit animations, we can add the following:

AnimatePresence>
    {isOpen && (
    <motion.p
        initial={{ opacity: 0, filter: "blur(4px)" }}
        animate={{ opacity: 1, filter: "blur(0px)" }}
        exit={{
        opacity: 0,
        filter: "blur(4px)",
        transition: { duration: 0.1 },
        }}
        transition={{ delay: 0.2 }}
    >
        I first sumbled across these mugs in Hens Teeth, Dublin where I
        had to grab a couple of them, and then I had the priveledge of
        visiting the store in Copenhagen and couldn't resist grabbing
        another.
    </motion.p>
    )}
</AnimatePresence>

To break this down further, we go from { opacity: 0, filter: "blur(4px)" } to { opacity: 1, filter: "blur(0px)" } when the accordion open which adds a subtle entrance for the text, we add transition={{ delay: 0.2 }} to wait for the card to get to a reasonable height before showing the text and we reduce the transition duration to 0.1 on exit to get rid of it faster.

Conclusion

There are a few things to remember when animating height in React:

Use a wrapper for motion and an inner container for the bounds ref
The wrapper should have overflow: hidden
Use AnimatePresence if you need exit animations

Got any questions? Feel free to reach out on X - @dbillson
